CR2016
EVE CR2016 Li-MnO2 Battery 3V 80mAh Lithium Primary Battery Car Key Remote Control Small Electronic Scale Weight Scale
-
3 Nominal Voltage（V）
-
80 Nominal Capacity（mAh)
-
0.1 Standard current（mA）
-
-20~+70℃ Operating Temperature (°C)
-
20.0×1.6 Sizes（mm）
-
0.1 Standard discharge current（mA）
Application Scenario
RFID, memory devices, remote controls, thermometers
Product Certification
Origin of Shipment：
China Warehouse -
Long Service Life
-
Multi Application Scenario
-
Comprehensive Solutions
-
Low Self-discharge Rate
-
High Stability Voltage
-
High Energy Density
-
Ultra Wide Temperature Applications
-
Fully Certified
-
Product Selection
-
Product Introduction
-
Specifications
-
Safety Precautions
Product Selection
Product Introduction
-
World-leading, Sales and export volume ranks No. 1 for 8yrsEVE has supplied over 3.5 billion lithium primary batteries to the world
-
CR2016 3V 80mAhHigh Pulse,Long Lifespan
Product CertificationMeet UL1642, UN38.3, ATEX, CE, ISO and other certificates
-
Intelligent Security Power Solutions12 years + long life, -40℃~85℃ ultra-wide temperature range
-
Recommended SolutionsIntelligent Smoke Sensor, Intelligent Door Lock, Combustible Gas Detection, Intelligent Home Appliance and other programs
-
Intelligent Security Power SolutionsOver 13 years of application verification, provide safe and reliable power supply for security equipment
-
Long lifespanExtremely long reliability life expectancy
Warm load discharge curve30KΩ Continuous Load Discharge Curve for Different Temperature Conditions
Temperature-loaded capacity graphCapacity curves at different temperatures and load conditions
Specifications
| Model | CR2016 |
| Nominal voltage | 3V |
| Nominal capacity | 80mAh （在 20±3℃环境下30KΩ放电至 2.0V) |
| Maximum Continuous Discharge Current | 3mA |
| Sizes(mm) | 20.0*1.6 |
| Weight（Max） | 1.8g |
| Recommended storage conditions | 温度：5℃~35℃，湿度：小于70%RH |
| Application scenario | 智能表计、智慧生活、汽车电子、物联网、智能安防 |
| Aperating temperature | -20~70℃ |
Safety Instructions
